DETAILS
Eco-solven printable vinyl
1、Information： | |||
Name： | Eco-solven printable vinyl | ||
Description | Special property, Use with computer, plotter and heat press machine, it is convenient. It can press on fabrics directly, and looks personalized than other vinyl. | ||
Parameter | |||
Liner | PET film | Transfertemperature | 150-160℃ |
certificate | Oeko-Tex100 | Transfer time | 8-10S |
Length/width | 50cm*25m/roll | Peel method | Cold peeling |
thickness | 0.1-0.12MM | effect | matting light |
It is Environmentally friendly | Transfer pressure | medium（6-8KG） | |
Melt point | 105℃ | Hand feeling | soft |
material | PU | color | white |
care | Wash temperature 40-60 degrees | fabrics | Cotton ,polyester,acrylic fibers,similar fibrous etc. |
Tumble dryer | |||
Iron form inside to outside | shopping way | ||
Wash by hand | Factory place | ||
industry | Apply to pictures in multi-color or single color,team logo/basketball number/advertisement/ company logo and so on,it is suitable for light color and dark color clothescan also use full color photographs,lookpersonalized. | ||
A. Instruction
1. Chose the photograph and adjust the color
2. Coating and adjust the rules of sending paper
【Tips:upside down(the right side of film take down,can feel it by hands )】
print and cut the picture,if by mimaki, force 120gf-140gf, speed: 15-20cm/s
3.Tear away other useless film
4.dry，solidify(according to the ink,regularly in 30mins)
5.Cut down the suitable area of transfer vinyl then attach together
6.Tear away other useless film
7.Cut down the picture(which is attached together )
9.heat print(according to fabrics,regular at 150-160℃,8-10s,pressure6-8kg)
10. Dry,solidify, and then tear away the release film when the temperature of the film drops below 40 ℃.
B. Attention
1）It is suitable for Eco-solvent ink
2）Cannot placed at the wet place long time, remember place it in black bag
3）It is not suitable for thick -lines fabrics,otherwise will see the lines of fabrics after transfer,it is not good to effects of fabrics（such as 3D、600D etc.）
4）After print, it needs some time and space for dry,and it can stick better.
5）Keep hand clean while use these products,otherwise it will affect the picture
